Description
3 x 16A adjustable mobile charger to charge your electric car from a red 16A 3-phase CEE socket. Type 2 connector with Tesla button. Black Glove!
Details
Our 11 kW 8 meter long Tesla mobile charger can be used to charge your Tesla from a red 16A 3-phase CEE socket. The power is adjustable to 3x6A, 3x10A, 3x13A or 3x16A. Your electric car is charged with a maximum of 11 kW. The Type 2 connector has the very practical Tesla button built in. (The charger can also be used to charge other electric cars/charging hybrids with Type 2 sockets).
The charger has a host of safety features, including CEE plug temperature monitoring, AC and DC residual current leakage detection, and overheating!
Make sure you charge from a properly installed red 16A CEE socket, which is rated to deliver 3x16A, installed with at least 2.5mm² wires.
The charger has:
Earth leakage protection (AC and DC)
Internal detection of power switching problems
Overcurrent protection
Surge protection
Low voltage protection
Short circuit protection
Overheating protection
Wall plug overheating protection
Adjustable charging amplifiers in A with 3 phases (3x6A, 3x10A, 3x13A or 3x16A)
This mobile charger also works if neutral and phase are reversed or if neutral is completely missing (3 x 230V network). Something that the charger from Tesla cannot deliver.
Specifications:
Connector type 2 female connector with Tesla control button
Cable 3-phase, 5 x 2.5 mm² + 0.75 mm². Nominal charging current: 3 x 16A (11 kW charging capacity) *
Color Grey/Black
IP rating IP65
Electrical connection CEE16 (red 5-pin connector for 16A)
Housing and dimensions Aluminum housing: height: 50mm x width: 80mm x length: 190mm - Total cable length: 8m
Weight 3.35 kg
Charging specification mode 3 / IEC 61851 communication device Complies with: with IEC 62196, IEC 61851-1, CE, EMC, RoHS
Charging output 16A / 3 Phase unit: max 11 kW @ 3-phase 400V
Overcurrent and fault protection RCD type A-EV (30mA AC, 6mA DC)
Status indication Tri-Color LED
Working temperature 40 C to 50 C° C
Battery for the button to the charger is sold as a spare part and is not covered by warranty.
The charging cables are assembled by hand in Belgium, which guarantees high quality and safety compared to many other Chinese cables. Cable is also CE approved and follows the IP-67 classification to be used in rainy weather. It is also on average 20% lighter compared to other cables cables from the Chinese market. All cables are quality assured and tested in the factory before they arrive at our warehouse, which is important to be able to guarantee the high quality and safety of this charging cable.
